| Part No. | 主频(MHz) | Flash | SRAM | I/O | GPTM (16bit) | Adv TM (16bit) | GPTM (32bit) | Bsc TM (16bit) | WDG | RTC | USART+UART | I2C | SPI | CAN 2.0 | USB/OTG | I2S | SDIO | LCD-TFT | Camera | MAC | IPA | RAM | 12bit ADC Units (CHs) | 12bit DAC Units | Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| GD32F450VET6 | 200 | 512K | 256K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+4 | 3 | 5 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 |
| GD32F450VGT6 | 200 | 1024K | 256K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+4 | 3 | 5 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 |
| GD32F450VIT6 | 200 | 2048K | 512K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+4 | 3 | 5 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 |
| GD32F450VKT6 | 200 | 3072K | 256K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+4 | 3 | 5 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 |
| GD32F450ZET6 | 200 | 512K | 256K | up to 114 | 8 | 2 | 2 | 2 | 2 | 1 | 4+4 | 3 | 6 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 |
| GD32F450ZGT6 | 200 | 1024K | 256K | up to 114 | 8 | 2 | 2 | 2 | 2 | 1 | 4+4 | 3 | 6 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 |
| GD32F450ZIT6 | 200 | 2048K | 512K | up to 114 | 8 | 2 | 2 | 2 | 2 | 1 | 4+4 | 3 | 6 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 |
| GD32F450ZKT6 | 200 | 3072K | 256K | up to 114 | 8 | 2 | 2 | 2 | 2 | 1 | 4+4 | 3 | 6 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 |
| GD32F450IGH6 | 200 | 1024K | 256K | up to 140 | 8 | 2 | 2 | 2 | 2 | 1 | 4+4 | 3 | 6 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | BGA176 |
| GD32F450IIH6 | 200 | 2048K | 512K | up to 140 | 8 | 2 | 2 | 2 | 2 | 1 | 4+4 | 3 | 6 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | BGA176 |
| GD32F450IKH6 | 200 | 3072K | 256K | up to 140 | 8 | 2 | 2 | 2 | 2 | 1 | 4+4 | 3 | 6 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | BGA176 |
| GD32F405RET6 | 168 | 512K | 192K | up to 51 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 3(16) | 2 | LQFP64 | ||||
| GD32F405RGT6 | 168 | 1024K | 192K | up to 51 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 3(16) | 2 | LQFP64 | ||||
| GD32F405RKT6 | 168 | 3072K | 192K | up to 51 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 3(16) | 2 | LQFP64 | ||||
| GD32F405VGT6 | 168 | 1024K | 192K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 3(16) | 2 | LQFP100 | ||||
| GD32F405VKT6 | 168 | 3072K | 192K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 3(16) | 2 | LQFP100 | ||||
| GD32F405VGH6 | 168 | 1024K | 192K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 3(16) | 2 | BGA100 | ||||
| GD32F405VKH6 | 168 | 3072K | 192K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 3(16) | 2 | BGA100 | ||||
| GD32F405ZGT6 | 168 | 1024K | 192K | up to 114 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 3(24) | 2 | LQFP144 | ||||
| GD32F405ZKT6 | 168 | 3072K | 192K | up to 114 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 3(24) | 2 | LQFP144 | ||||
| GD32F407RET6 | 168 | 512K | 192K | up to 51 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 3(16) | 2 | LQFP64 | |||
| GD32F407RGT6 | 168 | 1024K | 192K | up to 51 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 3(16) | 2 | LQFP64 | |||
| GD32F407RKT6 | 168 | 3072K | 192K | up to 51 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 3(16) | 2 | LQFP64 | |||
| GD32F407VET6 | 168 | 512K | 192K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 | ||
| GD32F407VGT6 | 168 | 1024K | 192K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 | ||
| GD32F407VKT6 | 168 | 3072K | 192K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 | ||
| GD32F407VEH6 | 168 | 512K | 192K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | BGA100 | ||
| GD32F407VGH6 | 168 | 1024K | 192K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | BGA100 | ||
| GD32F407VKH6 | 168 | 3072K | 192K | up to 82 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | BGA100 | ||
| GD32F407ZET6 | 168 | 512K | 192K | up to 114 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 | ||
| GD32F407ZGT6 | 168 | 1024K | 192K | up to 114 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 | ||
| GD32F407ZKT6 | 168 | 3072K | 192K | up to 114 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 | ||
| GD32F407IEH6 | 168 | 512K | 192K | up to 140 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | BGA176 | ||
| GD32F407IGH6 | 168 | 1024K | 192K | up to 140 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | BGA176 | ||
| GD32F407IKH6 | 168 | 3072K | 192K | up to 140 | 8 | 2 | 2 | 2 | 2 | 1 | 4+2 | 3 | 3 | 2 | FS+HS | 2 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | BGA176 | ||
| GD32F403RCT6 | 168 | 256K | 64K | up to 51 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 0/0 | 3(16) | 2 | LQFP64 | |||||
| GD32F403RET6 | 168 | 512K | 96K | up to 51 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 0/0 | 3(16) | 2 | LQFP64 | |||||
| GD32F403RGT6 | 168 | 1024K | 128K | up to 51 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 0/0 | 3(16) | 2 | LQFP64 | |||||
| GD32F403RIT6 | 168 | 2048K | 128K | up to 51 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 0/0 | 3(16) | 2 | LQFP64 | |||||
| GD32F403RKT6 | 168 | 3072K | 128K | up to 51 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 0/0 | 3(16) | 2 | LQFP64 | |||||
| GD32F403VCT6 | 168 | 256K | 64K | up to 80 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(16) | 2 | LQFP100 | |||||
| GD32F403VET6 | 168 | 512K | 96K | up to 80 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(16) | 2 | LQFP100 | |||||
| GD32F403VGT6 | 168 | 1024K | 128K | up to 80 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(16) | 2 | LQFP100 | |||||
| GD32F403VIT6 | 168 | 2048K | 128K | up to 80 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(16) | 2 | LQFP100 | |||||
| GD32F403VKT6 | 168 | 3072K | 128K | up to 80 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(16) | 2 | LQFP100 | |||||
| GD32F403VCH6 | 168 | 256K | 64K | up to 80 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(16) | 2 | BGA100 | |||||
| GD32F403VEH6 | 168 | 512K | 96K | up to 80 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(16) | 2 | BGA100 | |||||
| GD32F403VGH6 | 168 | 1024K | 128K | up to 80 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(16) | 2 | BGA100 | |||||
| GD32F403VIH6 | 168 | 2048K | 128K | up to 80 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(16) | 2 | BGA100 | |||||
| GD32F403VKH6 | 168 | 3072K | 128K | up to 81 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(16) | 2 | BGA100 | |||||
| GD32F403ZCT6 | 168 | 256K | 64K | up to 112 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(21) | 2 | LQFP144 | |||||
| GD32F403ZET6 | 168 | 512K | 96K | up to 112 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(21) | 2 | LQFP144 | |||||
| GD32F403ZGT6 | 168 | 1024K | 128K | up to 112 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(21) | 2 | LQFP144 | |||||
| GD32F403ZIT6 | 168 | 2048K | 128K | up to 112 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(21) | 2 | LQFP144 | |||||
| GD32F403ZKT6 | 168 | 3072K | 128K | up to 112 | 8 | 2 | 2 | 2 | 1 | 3+2 | 2 | 3 | 2 | OTG | 2 | 1 | 1/0 | 3(21) | 2 | LQFP144 |
GigaDevice GD32F4系列全新32位通用MCU，基于200MHz Cortex®-M4内核，持续以业界领先的强大处理效能、高集成度、高可靠性和易用性的最佳组合，为高性能计算需求提供高性价比解决方案。
- 配备了512KB到3072KB的片上Flash及256KB到512KB的SRAM
- 双区块(dual-bank)闪存允许同步读写操作
- 采用2.6V-3.6V供电，I/O口可承受5V电平
- 提供了完整的DSP指令集、并行计算能力和专用浮点运算单元(FPU)
- 为应对多个外设同时运行和嵌入式软件协议栈的资源开销，配备了512KB到3072KB的超大容量内置Flash及多达192KB的SRAM
- 芯片采用2.6V-3.6V供电
- 提供了完整的DSP指令集、并行计算能力和专用提供了20个产品型号，包括LQFP144、LQFP100、LQFP64和BGA100等4种封装类型选择
- 最高主频可达168MHz，集成了完整的DSP指令集、并行计算能力和专用浮点运算单元（FPU）
- 配备了256KB到3072KB的超大容量Flash及64KB到128KB的SRAM
选型表下载
开发板型号
- Easy-GD32F450
支持芯片
- GD32F45Vx
示例代码
