Product	Description	Compliance	Status	V(BR)CES Typ (V)	IC Max (A)	VCE(sat) Typ (V)	VF Typ (V)	Eoff Typ (mJ)	Eon Typ (mJ)	Trr Typ (ns)	Irr Typ (A)	Gate Charge Typ (nC)	Short Circuit Withstand (µs)	EAS Typ (mJ)	PD Max (W)	Co-Packaged Diode	Package Type
FGAF20S65AQ	IGBT, 650 V, 20A Field Stop Trench	Pb-free	ActiveNEW	650	20	1.4	1.3	0.056	0.2	235		38			75	No	TO-3PF-3L
FGAF30S65AQ	IGBT, 650 V,30A Field Stop Trench	Pb-free	ActiveNEW	650	30	1.4	1.3	0.082	0.295	267		58			83	No	TO-3PF-3L
FGD2736G3-F085V	IGBT, EcoSPARK® 3 270mJ, 360V, N-Channel Ignition	AEC Qualified PPAP Capable Pb-free Halide free	ActiveNEW	360	18	1.65	-	-	-	3000	-	-	-	-	150	No	DPAK-3
FGHL75T65MQD	IGBT - 650 V 75 A FS4 medium switching speed IGBT	Pb-free Halide free	ActiveNEW	650 V	75 A	1.45 V	2.3 V	1.55 mJ	1.94 mJ	36 ns	250 µA	145 nC	NA	NA	375 W	Yes	TO-247-3LD
ISL9V3040D3STV	IGBT, N-Channel Ignition, DPAK, 17A, 1.58V, 300mJ EcoSPARK® I	AEC Qualified PPAP Capable Pb-free Halide free	ActiveNEW	400	17	1.6	-	-	-	-	-	17	-	-	150	No	DPAK-3
ISL9V2040D3STV	IGBT, 430V, 10A, 1.95V, 200mJ, DPAK EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Product Preview														DPAK-3
ISL9V3036D3STV	IGBT, 360V, 17A, 1.58V, 300mJ, D2PAK EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Product Preview														DPAK-3
AFGB30T65SQDN	IGBT 650V FS4 High speed version for OBC application in D2PAK	AEC Qualified PPAP Capable Pb-free	Active	650	30	1.6	1.5	0.16	0.786	131		56	-	-	220	Yes	D2PAK-3 / TO-263-2
AFGB40T65SQDN	IGBT, 650V FS4 High speed version, for OBC application in D2pak	AEC Qualified PPAP Capable Pb-free	Active	650	40	1.6	1.5	0.229	0.858	131		76	-	-	238	Yes	D2PAK-3 / TO-263-2
AFGHL40T65SPD	IGBT, 650V 40A in TO247 providing enhanced Final Test coverage for betterand robuster performance.	AEC Qualified PPAP Capable Pb-free	Active														TO-247-3LD
AFGHL50T65SQDC	Hybrid IGBT, 650V, 50A Fieldstop 4 trench IGBT with SiC-SBD	AEC Qualified PPAP Capable Pb-free	Active	650V	50A	1.6V	1.45V					94				Yes	TO-247-3LD
FGA15N120ANTDTU	IGBT, 1200V, 15A, NPT Trench	Pb-free	Active	1200			1.7	0.6	3		27	120	-	-	186		TO-3P-3L
FGA15S125P	IGBT, 1250V, 15A, Shorted-anode	Pb-free	Active	1250	15	2.25	2	0.5	0.74	-	-	129	-	-	136	Yes	TO-3P-3L
FGA20N120FTD	IGBT, 1200V, 20A, Field Stop Trench	Pb-free	Active	1200	20	1.6	1.3	0.71	0.42	485	48	137	-	-	298	Yes	TO-3P-3L
FGA20S125P	IGBT, 1250V, 20A, Shorted-anode	Pb-free	Active	1250			1.75	0.5	0.74	-	-	153	-	-	250		TO-3P-3L
FGA20S140P	IGBT, 1400V, 20A, Shorted-anode	Pb-free	Active	1400	20	1.9	1.7	0.56	0.76	-	-	203.5	-	-	272	Yes	TO-3P-3L
FGA25N120ANTDTU	IGBT, 1200V, 25A, NPT Trench	Pb-free	Active	1200			2	0.96	4.1		27	200	-	-	312		TO-3P-3L
FGA25S125P	IGBT, 1250V, 25A, Shorted-anode	Pb-free	Active	1250			2.1	0.58	1.085	-	-	204	-	-	250		TO-3P-3L
FGA3060ADF	IGBT, 600 V, 30 A Field Stop Trench	Pb-free Halide free	Active	600	30	1.8	1.6	0.165	0.96	26	-	37.4	-	-	176	Yes	TO-3P-3L
FGA30N120FTD	IGBT, 1200V, 30A, Field Stop Trench	Pb-free	Active	1200	30	1.6	1.3	1.16	0.54	775	43	208	-	-	339	Yes	TO-3P-3L
FGA30N65SMD	IGBT, 650V, 30A, Field Stop	Pb-free	Active	650	30	1.98	2.1	0.208	0.716	35	-	87	-	-	300	Yes	TO-3P-3L
FGA30S120P	IGBT, 1300V, 30A, Shorted-anode	Pb-free	Active	1300	30	1.75	1.7	1.22	1.3	-	-	78	-	-	348	Yes	TO-3P-3L
FGA30T65SHD	IGBT, 650 V, 30 A Field Stop Trench	Pb-free Halide free	Active	650	30	1.6	2.2	0.167	0.598	192	-	54.7	-	-	238	Yes	TO-3P-3L
FGA4060ADF	IGBT, 600 V, 40 A Field Stop Trench	Pb-free Halide free	Active	600	40	1.8	1.6	0.25	1.37	26	-	55.5	-	-	238	Yes	TO-3P-3L
FGA40N65SMD	IGBT, 650V, 40A, Field Stop	Pb-free	Active	650	40	1.9	2.1	0.26	0.34	200	3.6	119	-	-	349	Yes	TO-3P-3L
FGA40S65SH	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free	Active	650	40	1.4	1.45	388	194	-	-	73	-	-	268	Yes	TO-3P-3L
FGA40T65SHD	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free	Active	650	40	1.6	2.2	0.297	1.01	192	-	72.2	-	-	268	Yes	TO-3P-3L
FGA40T65SHDF	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free	Active	650	40	1.45	1.5	0.44	1.22	238	-	68	-	-	268	Yes	TO-3P-3L
FGA40T65UQDF	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free	Active	650	40	1.33	1.5	0.31	0.989	251	-	306	-	-	231	Yes	TO-3P-3L
FGA5065ADF	IGBT, 650 V, 50 A Field Stop Trench	Pb-free Halide free	Active	650	50	1.7	2.1	0.309	1.35	192	-	72.2	-	-	268	Yes	TO-3P-3L
FGA50N100BNTD	IGBT, 1000V, NPT Trench	Pb-free	Active	1000	35	2.5	1.2	-	-	1.2	-	275	-	-	156	Yes	TO-3P-3L
FGA50N100BNTD2	IGBT, 1000V, NPT Trench	Pb-free Halide free	Active	1000	35	2.5	2.9	-	-	60	-	257	-	-	156	Yes	TO-3P-3L
FGA50S110P	IGBT, 1100V, 50A, Shorted-anode	Pb-free	Active	1100	30	2.06	1.96	0.99	2.24	-	-	195	-	-	300	Yes	TO-3P-3L
FGA50T65SHD	IGBT, 650 V, 50 A Field Stop Trench	Pb-free Halide free	Active	650	50	1.6	2.3	0.384	1.28	197	-	87	-	-	319	Yes	TO-3P-3L
FGA6065ADF	IGBT, 650 V, 60 A Field Stop Trench	Pb-free Halide free	Active	650	60	1.8	1.8	0.52	2.46	271	-	84	-	-	306	No	TO-3P-3L
FGA60N60UFD	IGBT, 600V, 60A, Field Stop	Pb-free	Active	600	60	1.9	2	0.81	1.81	179	-	188	-	-	298	Yes	TO-3P-3L
FGA60N65SMD	IGBT, 650V, 60A, Field Stop	Pb-free	Active	650	60	1.9	2.1	0.45	1.54	212	-	189	-	-	600	Yes	TO-3P-3L
FGA6530WDF	IGBT, 650 V, 30 A Field Stop Trench	Pb-free Halide free	Active	650	30	1.8	1.7	0.162	0.96	81	-	37.4	-	-	176	Yes	TO-3P-3L
FGA6540WDF	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free	Active	650	40	1.8	1.5	0.25	1.37	238	-	55.5	-	-	238	Yes	TO-3P-3L
FGA6560WDF	IGBT, 650 V, 60 A Field Stop Trench	Pb-free Halide free	Active	650	60	1.8	1.8	0.52	2.46	271	-	84	-	-	306	Yes	TO-3P-3L
FGAF20N60SMD	IGBT, 600V, 20A, Field Stop	Pb-free	Active	600	20	1.7	2.3	0.141	0.452	88.2	-	64	-	-	75	Yes	TO-3PF-3L
FGAF40N60SMD	IGBT, 600V, 40A, Field Stop	Pb-free	Active	600	40	1.9	2.3	0.26	0.87	110	-	119	-	-	115	Yes	TO-3PF-3L
FGAF40N60UF	IGBT, 600V, PT	Pb-free	Active	600	20	2.3	-	0.13	0.47	-	-	77	-	-	100	No	TO-3PF-3L
FGAF40S65AQ	IGBT, 650 V, 40 A Field Stop Trench	Pb-free	Active	650	40	1.6	1.2V	0.062	0.132	274	-	75	-	-	94	No	TO-3PF-3L
FGB20N60SF	IGBT, 600V, 20A, 2.2V, TO-247 High Speed Field Stop	Pb-free Halide free	Active	600	20	2.2	-	0.16	0.37	-	-	65	-	-	208	No	D2PAK-3 / TO-263-2
FGB20N60SFD	IGBT, 600V, 20A, Field Stop	Pb-free Halide free	Active	600	20	2.2	1.9	0.16	0.37	57	-	65	-	-	208	Yes	D2PAK-3 / TO-263-2
FGB20N60S_F085	IGBT, 600V, 20A, 2.2V, D2PAK Field Stop	AEC Qualified PPAP Capable Pb-free	Active	600	40		1.9	0.13	0.31	111	-	63	-	-	208		D2PAK-3 / TO-263-2
FGB3040CS_F085	IGBT, 430V, 19A, 1.6V, 300mJ, D2PAK, Current Sensing EcoSPARK® I,N-Channel Ignition	AEC Qualified PPAP Capable Pb-free	Active	430	19	1.85	-	-	-	1500	-	15	-	-	150	Yes	D2PAK-6 / TO-263-6
FGB3040G2-F085C	IGBT, 400V, 26A, 1.35V, 300mJ, D2PAK EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active	400	26	1.5				1900		21			150		D2PAK-3 / TO-263-2
FGB3040G2_F085	IGBT, 400V, 26A, 1.35V, 300mJ, D2PAK EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active	-			-	-	-	1900	-	21	-	-	150	-	D2PAK-3 / TO-263-2
FGB3056_F085	IGBT, EcoSPARK® 300mJ, 560V, N-Channel Ignition	AEC Qualified PPAP Capable Pb-free Halide free	Active	560	29	560	-	-	-	1480	-	15.6	-	-	200	-	D2PAK-3 / TO-263-2
FGB3236_F085	IGBT, 360V, 27A, 1.32V, 320mJ, EcoSPARK® II, N-Channel Ignition	AEC Qualified PPAP Capable Pb-free	Active	360			-	-	-	1700	-	-	-	-	187	Yes	D2PAK-3 / TO-263-2
FGB3245G2_F085	IGBT, 450V, 23A, 1.3V, 320mJ, EcoSPARK® II, N-Channel Ignition	AEC Qualified PPAP Capable Pb-free Halide free	Active	450			-	-	-	2600	-	-	-	-	150	Yes	D2PAK-3 / TO-263-2
FGB3440G2_F085	IGBT, 400V, 25A, 1.30V, 335mJ, EcoSPARK® II, N-Channel Ignition	AEC Qualified PPAP Capable Pb-free Halide free	Active	400			-	-	-	2000	-	-	-	-	166	-	D2PAK-3 / TO-263-2
FGB40N60SM	IGBT, 600V, 40A, Field Stop	Pb-free Halide free	Active	600	40	1.9	-	0.26	0.87	-	-	119	-	-	349	No	D2PAK-3 / TO-263-2
FGB40T65SP_F085	IGBT, 650V, 40A Field Stop Trench	AEC Qualified PPAP Capable Pb-free	Active	650			2	0.28	0.97		-	36	5	-	267		D2PAK-3 / TO-263-2
FGB5N60UNDF	IGBT, 600V, 5A, Short Circuit Rated	Pb-free Halide free	Active	600	5	1.9	1.7	0.07	0.08	87	-	12.1	-	-	73.5	Yes	D2PAK-3 / TO-263-2
FGB7N60UNDF	IGBT, 600V, 7A, Short Circuit Rated	Pb-free Halide free	Active	600	7	1.9	1.7	104	99	70	-	18	-	-	83	Yes	D2PAK-3 / TO-263-2
FGBS3040_F085	Integrated Smart Ignition Coil Driver	AEC Qualified PPAP Capable Pb-free Halide free	Active	600	6.8	-	-	-	-	-	-	-	-	-	150	-	D2PAK-7 / TO-263-7
FGD2736G3_F085	IGBT, EcoSPARK® 3 270mJ, 360V, N-Channel Ignition	AEC Qualified PPAP Capable Pb-free Halide free	Active	360			-	-	-	3000	-	-	-	-	150	-	DPAK-3 / TO-252-3
FGD3040G2-F085C	IGBT,N-Channel Ignition,DPAK,26A, 1.35V, 300mJ EcoSPARK® II	AEC Qualified PPAP Capable Pb-free Halide free	Active	400	26	1.5				1900		21			150		DPAK-3 / TO-252-3
FGD3040G2-F085V	IGBT,N-Channel Ignition,DPAK,26A, 1.35V, 300mJ EcoSPARK® II	AEC Qualified PPAP Capable Pb-free Halide free	Active														DPAK-3
FGD3040G2_F085	IGBT, 400V, 26A, 1.35V, 300mJ, DPAK EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active	400			-	-	-	1900	-	21	-	-	150	-	DPAK-3 / TO-252-3
FGD3050G2	IGBT, 500V, 27A, 1.3V, 300mJ, DPAK EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active	495	32	1.1			300	1.6		22		300	150		DPAK-3 / TO-252-3
FGD3050G2V	IGBT, 500V, 27A, 1.3V, 300mJ, DPAK EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active														DPAK-3
FGD3245G2-F085C	IGBT,N-Channel Ignition, DPAK,1.3V, 320mJ, EcoSPARK® II	AEC Qualified PPAP Capable Pb-free Halide free	Active	450	23	1.25				2600		23			150		DPAK-3 / TO-252-3
FGD3245G2-F085V	IGBT,N-Channel Ignition, DPAK,1.3V, 320mJ, EcoSPARK® II	AEC Qualified PPAP Capable Pb-free Halide free	Active														DPAK-3
FGD3245G2_F085	IGBT, 450V, 23A, 1.3V, 320mJ, DPAK EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active	450			-	-	-	2600	-	23	-	-	150	-	DPAK-3 / TO-252-3
FGD3325G2-F085V	IGBT, 250V, 25A, 1.35V, 330mJ, EcoSPARK®2, N-Channel Ignition	AEC Qualified PPAP Capable Pb-free Halide free	Active														DPAK-3
FGD3325G2_F085	IGBT, 250V, 25A, 1.35V, 330mJ, EcoSPARK®2, N-Channel Ignition	AEC Qualified PPAP Capable Pb-free Halide free	Active	250			-	-	-	1200	-	21	-	-	150	-	DPAK-3 / TO-252-3
FGD3440G2-F085V	IGBT, 400V, 25A, 1.30V, 335mJ, DPAK EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active														DPAK-3
FGD3440G2_F085	IGBT, 400V, 25A, 1.30V, 335mJ, DPAK EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active	400			-	-	-	2000	-	24	-	-	166	-	DPAK-3 / TO-252-3
FGD3N60LSD	IGBT, 600V, 3A, 1.2V, DPAK, Planar	AEC Qualified PPAP Capable Pb-free Halide free	Active	600	6	1.2	1.5	1	0.25	234	2.64	12.5	-	-	40	Yes	DPAK-3 / TO-252-3
FGD3N60UNDF	IGBT, 600V, 3A, Short Circuit Rated	Pb-free Halide free	Active	600	3	2	1.7	0.3	0.52	21	-	1.6	10	-	60	Yes	DPAK-3 / TO-252-3
FGD5T120SH	IGBT, 1200 V, 5 A FS Trench	Pb-free Halide free	Active	1200	5	2.9	-	0.94	0.247	-	-	6.7	-	-	69	No	DPAK-3 / TO-252-3
FGH12040WD_F155	IGBT, 1200 V, 40 A Field Stop Trench	Pb-free	Active	1200			3.6	1	6.9		6.8	226	5	-	428		TO-247-3
FGH15T120SMD	IGBT, 1200V, 15A, Field Stop Trench	Pb-free	Active	1200			2.8	0.46	1.15		12	128	-	-	333		TO-247-3
FGH20N60SFD	IGBT, 650V, 20A, 2.2V, TO-247 High Speed Field Stop	Pb-free Halide free	Active	600	20	2.2	1.9	0.13	0.43	34	-	66	-	-	165	Yes	TO-247-3
FGH20N60SF_F085	IGBT, 600V, 20A, 1.9V, TO-247 Field Stop	AEC Qualified PPAP Capable Pb-free	Active	600	40		1.9	0.13	0.43	40	-	66	-	-	165		TO-247-3
FGH20N60UFD	IGBT, 600V, 20A, Field Stop	Pb-free Halide free	Active	600	20	1.8	1.9	0.26	0.38	57	-	63	-	-	165	Yes	TO-247-3
FGH25N120FTDS	IGBT, 1200V, 25A, Field Stop Trench	Pb-free	Active	1200	25	1.6	2.5	1.16	1.42	496	5.2	169	-	-	313	Yes	TO-247-3
FGH25T120SMD	IGBT, 1200V, 25A Field Stop Trench	Pb-free	Active	1200			2.8	0.56	1.74	325	13	225	-	-	428		TO-247-3
FGH30N60LSD	IGBT, 600V, 30A, PT	Pb-free Halide free	Active	600	30	1.1										Yes	TO-247-3
FGH30S130P	IGBT, 1300V, 30A, Shorted-anode	Pb-free	Active	1300	30	1.75	1.7	1.22	1.3	-	-	372.3	-	-	500	Yes	TO-247-3
FGH30S150P	IGBT, 1500 V, 30 A Shorted-anode	Pb-free	Active	1500	30	1.85	1.61	0.9	1.16	-	-	369	-	-	500	Yes	TO-247-3
FGH40N120AN	IGBT, 1200V, NPT	Pb-free	Active	1200	40	2.6	-	1.1	2.3	-	-	220	10	-	417	No	TO-247-3
FGH40N60DF_F085	IGBT, 600V, 40A, 1.9V, TO-247 Field Stop	AEC Qualified PPAP Capable Pb-free	Active	600	80		1.3	0.25	1.3	57	-	122	-	-	349		TO-247-3
FGH40N60SF	IGBT, 600V, 40A, 2.3V, TO-247 High Speed Field Stop	Pb-free Halide free	Active	600	40	2.3	-	0.31	1.13	-	-	120	-	-	290	No	TO-247-3
FGH40N60SFD	IGBT, 600V, 40A, Field Stop	Pb-free Halide free	Active	600	40	2.3	1.8	0.38	1.23	68	-	121	-	-	290	Yes	TO-247-3
FGH40N60SF_F085	IGBT, 600V, 40A, 2.3V, TO-247 High Speed, Field Stop	AEC Qualified PPAP Capable Pb-free	Active	600	80		1.8	0.38	1.23	68	-	121	-	-	290		TO-247-3
FGH40N60SMD	IGBT, 600V, 40A, 1.9V, TO-247 Field Stop	Pb-free Halide free	Active	600	40	1.9	-	-	-	36	-	-	-	-	-	Yes	TO-247-3
FGH40N60SMDF	IGBT, 600V, 40A, 1.9V, TO-247 Field Stop	Pb-free Halide free	Active	600	40	1.9	1.3	0.25	1.3	57	-	122	-	-	349	Yes	TO-247-3
FGH40N60SM_F085	IGBT, Field Stop, 600 V, 40 A, 1.9 V	AEC Qualified PPAP Capable Pb-free	Active	600	80		2.3	0.3	0.92	36	-	119	-	-	349		TO-247-3
FGH40N60UF	IGBT, 600V, 40A, Field Stop	Pb-free Halide free	Active	600	40	1.8	-	0.46	1.19		-	120	-	-	290	No	TO-247-3
FGH40N60UFD	IGBT, 600V, 40A, Field Stop	Pb-free Halide free	Active	600	40	1.8	1.95	0.46	1.19	45	-	120	-	-	290	Yes	TO-247-3
FGH40N65UFD	IGBT, 650V, 40A, 1.8V, TO-247 Low VCE(ON) Field Stop	Pb-free Halide free	Active	650	40	1.8	1.8	0.79	1.62	65	-	119	-	-	290	Yes	TO-247-3
FGH40N65UF_F085	IGBT, 650V, 40A, 1.8V, TO-247 Field Stop	AEC Qualified PPAP Capable Pb-free	Active	650	80		1.8	0.5	1.28	65	-	119	-	-	290		TO-247-3
FGH40T100SMD	IGBT, 1000V, 40A, Field Stop Trench	Pb-free Halide free	Active	1000	40	1.9	3.4	1.15	2.35	256	-	265	-	-	333	Yes	TO-247-3
FGH40T120SMD	IGBT, 1200V, 40A Field Stop Trench	Pb-free	Active	1200	40	1.8	3.8	1.1	2.7	200	18	370	-	-	555	Yes	TO-247-3
FGH40T120SMDL4	IGBT, 1200 V, 40 A FS Trench	Pb-free Halide free	Active	1200	40	1.8	3.8	1.02	2.24	200	7.2	370	-	-	555	Yes	TO-247-4
FGH40T120SQDNL4	IGBT, Ultra Field Stop	Pb-free Halide free	Active	1200	40	1.78	3.4	1.1	2.7	166	9	221	0		227	Yes	TO-247-4
FGH40T65SH	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free	Active	650			-	0.297	1.01	-	-	72.2	-	-	268		TO-247-3
FGH40T65SHD	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free	Active	650			2.2	0.297	1.01		-	72.2	-	-	268		TO-247-3
FGH40T65SHDF	IGBT, 650V, 40A Field Stop Trench	Pb-free Halide free	Active	650			1.5	0.44	1.22		-	68	-	-	268		TO-247-3
FGH40T65SPD	IGBT, 650V, 40A Field Stop Trench	Pb-free	Active	650			2.2	0.28	1.16		-	35	5	-	267		TO-247-3
FGH40T65SP_F085	IGBT, 650V, 40A Field Stop Trench	AEC Qualified PPAP Capable Pb-free	Active	650	80		2.2	0.27	1.16	35	-	36	5	-	267	Yes	TO-247-3
FGH40T65SQD	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free	Active	650	40	1.6	2.2	0.052	0.138	31.8	-	80	-	-	238	Yes	TO-247-3
FGH40T65UQDF	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free	Active	650			1.5	0.31	0.989		-	306	-	-	231		TO-247-3
FGH40T70SHD	IGBT, 700 V, 40 A Field Stop Trench	Pb-free Halide free	Active	700			2	0.271	1.15		-	69	-	-	268		TO-247-3
FGH50N3	IGBT, 300V, SMPS	Pb-free	Active	300	75	1.3	-	0.92	0.13	-	-	180	8	800	463	No	TO-247-3
FGH50T65SQD-F155	IGBT, 650 V, 50A Field Stop 4 Trench	Pb-free Halide free	Active	650			2.2	0.11	0.402		-	99	-	-	268		TO-247-3
FGH60N60SF	IGBT, 600V, 60A, 2.2V, TO-247 High Speed Field Stop	Pb-free Halide free	Active	600	60	2.2	-	0.67	1.79	-	-	198	-	-	378	No	TO-247-3
FGH60N60SFDTU	IGBT, Field Stop, 600V, 60A	Pb-free Halide free	Active	600	60	2.3	-	0.67	1.79	179	-	198	-	-	378	Yes	TO-247-3
FGH60N60SF_F085	IGBT, 600V, 60A, 2.2V, TO-247 High Speed, Field Stop	AEC Qualified PPAP Capable Pb-free	Active	600	120		1.9	0.57	1.97	55	-	188	-	-	378		TO-247-3
FGH60N60SMD	IGBT, 600V, 60A, Field Stop	Pb-free Halide free	Active	600	60	1.9	2.1	0.39	1.59	72	-	187	-	-	600	Yes	TO-247-3
FGH60N60SM_F085	IGBT, 600V, 60A, 1.8V, TO-247 Field Stop	AEC Qualified PPAP Capable Pb-free	Active	600	120		2.1	0.39	1.59	33	-	187	-	-	600		TO-247-3
FGH60N60UFD	IGBT, 600V, 20A, 1.8V, TO-247 Low VCE(ON) Field Stop	Pb-free Halide free	Active	600	60	1.8	1.7	0.81	2.47	47	-	192	-	-	298	Yes	TO-247-3
FGH60N60UF_F085	IGBT, 600V, 60A, 1.8V, TO-247 Field Stop	AEC Qualified PPAP Capable Pb-free	Active	600	120		1.7	0.81	2.47	76	-	192	-	-	298		TO-247-3
FGH60T65SHD	IGBT, 650 V, 60 A Field Stop Trench	Pb-free Halide free	Active	650			2.3	0.63	1.69		-	102	-	-	349		TO-247-3
FGH60T65SQD-F155	IGBT, 650 V, 60 A Field Stop Trench	Pb-free Halide free	Active	650	60	1.6	2.3	0.167	0.585	34.6	null	79			333		TO-247-3
FGH75N60UF	IGBT, 600V, 75A, Field Stop	Pb-free Halide free	Active	600	75	1.9	-	1.35	3.05	-	-	250	-	-	452	No	TO-247-3
FGH75T65SHD	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free	Active	650			2.2	0.72	2.4		-	123	-	-	455		TO-247-3
FGH75T65SHDT	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free	Active	650			1.8	0.75	3	76	-	123	-	-	455		TO-247-3
FGH75T65SHDTL4	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free	Active	650	75	1.6	1.8	1.56	1.06	76	-	126	-	-	455	Yes	TO-247-4
FGH75T65SHDTLN4	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free	Active														TO-247 4-LEAD, THIN LEADS
FGH75T65SQD	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free	Active	650			2	0.18	0.76		-	128	-	-	375		TO-247-3
FGH75T65SQDNL4	IGBT, Field Stop IV/4 Lead	Pb-free Halide free	Active	650	75	1.43	1.6	1.26	1.25	134	10	128			375	Yes	TO-247-4
FGH75T65SQDT	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free	Active	650	75	1.6	1.8	0.18	0.76	76	-	128	-	-	375	Yes	TO-247-3
FGH75T65SQDTL4	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free	Active	650	75	1.6	1.8	0.266	0.307	76	-	128	-	-	375	Yes	TO-247-4
FGH80N60FD	IGBT, 600V, Field Stop	Pb-free Halide free	Active	600	40	1.8	2.3	0.52	1	105	2.6	120	-	-	290	Yes	TO-247-3
FGH80N60FD2	IGBT, 600V, Field Stop	Pb-free Halide free	Active	600	40	1.8	1.2	0.52	1	125	4.8	120	-	-	290	Yes	TO-247-3
FGHL40S65UQ	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free	Active	650	40	1.36	1.24	0.362	1.76	319	-	304	-	-	192	No	TO-247-3LD
FGHL50T65SQ	IGBT 650V FS4 High speed version for PFC application in TO-247	Pb-free Halide free	Active	650	50	1.6	-	0.088	0.41	-	-	99	-	-	268	No	TO-247-3LD
FGI3040G2_F085	IGBT, 400V, 26A, 1.35V, 300mJ, TO-262 EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active	400			-	-	-	1900	-	21	-	-	150	-	I2PAK-3 / D2PAK-3 STRAIGHT LEAD
FGI3236_F085	IGBT, 360V, 27A, 1.32V, 320mJ, TO-262 EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active	360			-	-	-	1700	-	20	-	-	187	-	I2PAK-3 / D2PAK-3 STRAIGHT LEAD
FGL12040WD	IGBT, 1200 V, 40 A Field Stop Trench	Pb-free	Active	1200	40	2.3	3.6	1	4.1	71	14	226	-	-	391	Yes	TO-264-3
FGL35N120FTD	IGBT, 1200V, 35A, Field Stop Trench	Pb-free	Active	1200	35	1.68	2.7	1.7	2.5	520	7.6	210	-	-	368	Yes	TO-264-3
FGL40N120AN	IGBT, 1200V, NPT	Pb-free	Active	1200	40	2.6	-	1.1	2.3	-	-	220	10	-	500	No	TO-264-3
FGL40N120AND	IGBT, 1200V, NPT	Pb-free	Active	1200	40	2.6	3.2	1.1	2.3	75	8	220	10	-	500	Yes	TO-264-3
FGP10N60UNDF	IGBT, 600V, 10A, Short Circuit Rated	Pb-free	Active	600	10	2	1.8	0.05	0.15	78.9	-	37	-	-	139	Yes	TO-220-3
FGP15N60UNDF	IGBT, 600V, 15A, Short Circuit Rated	Pb-free	Active	600	15	2.2	1.6	0.067	0.37	142	-	43	-	-	178	Yes	TO-220-3
FGP20N60UFD	IGBT, 600V, 20A, Field Stop	Pb-free	Active	600	20	1.8	1.9	0.26	0.38	57	-	63	-	-	165	Yes	TO-220-3
FGP3040G2_F085	IGBT, 400V, 26A, 1.35V, 300mJ, TO-220 EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active	400			-	-	-	1.9	-	21	-	-	150	Yes	TO-220-3
FGP3440G2_F085	IGBT, 400V, 25A, 1.30V, 335mJ, TO-220 EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active	400			-	-	-	2000	-	24	-	-	166	Yes	TO-220-3
FGP5N60LS	IGBT, 600V, 5A, Field Stop	Pb-free	Active	600	5	1.7	-	130	38	-	-	18.3	-	-	83	No	TO-220-3
FGPF10N60UNDF	IGBT, 600V, 10A, Short Circuit Rated	Pb-free	Active	600	10	2	1.8	0.05	0.15	78.9	-	37	10	-	42	Yes	TO-220-3 FullPak
FGPF15N60UNDF	IGBT, 600V, 15A, Short Circuit Rated	Pb-free	Active	600	15	2.2	1.6	0.067	0.37	142	-	43	-	-	42	Yes	TO-220-3 FullPak
FGPF4565	IGBT, 650 V Field Stop Trench	Pb-free Halide free	Active	650	170	1.5	-	-	-	-	-	40.3	-	-	30	No	TO-220-3 FullPak
FGY100T65SCDT	IGBT, Field Stop Trench, Short Circuit Rated, 650 V, 100 A	Pb-free Halide free	Active	650	100	1.5	1.68	5.2	9.7	62	-	157	5	-	750	Yes	TO-247-3
FGY120T65S_F085	IGBT, 650V, 120A Field Stop, Trench With Soft Fast Recovery Diode	AEC Qualified PPAP Capable Pb-free	Active	650	240		1.3	3.5	6.8	123	-	162	6	-	882		TO-247-3
FGY160T65S_F085	IGBT, 650V, 160A Field Stop, Trench With Soft Fast Recovery Diode	AEC Qualified PPAP Capable Pb-free	Active	650	240		1.4	5.7	12.4	132	-	163	6	-	882		TO-247-3
FGY40T120SMD	IGBT, 1200 V, 40 A Field Stop Trench	Pb-free Halide free	Active	1200	40	1.8	3.8	1.1	2.7	200	-	370	-	-	882	Yes	TO-247-3
FGY60T120SQDN	IGBT, Ultra Field Stop -1200V 60A	Pb-free Halide free	Active	1200	60	1.7											TO-247-3
FGY75N60SMD	IGBT, 600V, 75A, Field Stop	Pb-free Halide free	Active	600	75	1.9	1.75	0.77	2.3	126	-	248	-	-	750	Yes	TO-247-3
FGY75T120SQDN	IGBT, Ultra Field Stop -1200V 75A	Pb-free Halide free	Active	1200	75	1.7	3.4	1.96	6.25	99	20	399			395	Yes	TO-247-3
HGT1S10N120BNS	IGBT, 1200V, NPT	Pb-free	Active	1200	17	2.45	-	0.8	0.32	-	-	100	8	80	298	No	D2PAK-3 / TO-263-2
HGTD1N120BNS	IGBT, 1200V, NPT	Pb-free	Active	1200	2.7	2.5	-	0.09	0.07	-	-	14	8	10	60	No	DPAK-3 / TO-252-3
HGTG18N120BND	IGBT, 1200V, NPT	Pb-free	Active	1200	26	2.45	-	1.8	1.9	44	-	165	8	-	390	Yes	TO-247-3
HGTG20N60A4	IGBT, 600V, SMPS	Pb-free	Active	600	40	1.8	-	0.15	0.28	-	-	142	-	-	290	No	TO-247-3
HGTG30N60A4	IGBT, 600V, SMPS	Pb-free	Active	600	60	1.8	-	0.24	0.28	-	-	225	-	-	463	No	TO-247-3
HGTG30N60B3	IGBT, 600V, PT	Pb-free	Active	600	30	1.45	-	0.68	0.5	-	-	170	-	100	208	No	TO-247-3
HGTP3N60A4	IGBT, 600V, SMPS	Pb-free	Active	600	8	2	-	0.025	0.037	-	-	21	-	12	70	No	TO-220-3
HGTP7N60A4	IGBT, 600V, SMPS	Pb-free	Active	600			-	0.06	0.055	-	-	37	-	25	125		TO-220-3
ISL9V2040D_F085	IGBT, 430V, 10A, 1.95V, 200mJ, DPAK EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free	Active	400	10	1.9	-	-	-	2170	-	12	-	-	130	-	DPAK-3 / TO-252-3
ISL9V2040S_F085	IGBT, 430V, 10A, 1.95V, 200mJ, DPAK EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free	Active	400	10	1.9	-	-	-	2170	-	12	-	-	130	-	D2PAK-3 / TO-263-2
ISL9V2540S_F085	IGBT, 430V, 15A, 1.77V, 250mJ, D2PAK EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free	Active	400	15	1.8	-	-	-	2170	-	15.1	-	-	166.7	-	D2PAK-3 / TO-263-2
ISL9V3036S_F085	IGBT, 360V, 17A, 1.58V, 300mJ, D2PAK EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free	Active	360	17	1.58	-	-	-	2100	-	17	-	-	150	-	D2PAK-3 / TO-263-2
ISL9V3040D3ST-F085C	IGBT, N-Channel Ignition, DPAK, 17A, 1.58V, 300mJ EcoSPARK® I	AEC Qualified PPAP Capable Pb-free	Active	400	17	1.6						17			150		DPAK-3 / TO-252-3
ISL9V3040D_F085	IGBT, 400V, 17A, 1.58V, 300mJ, DPAK EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free	Active	400	17	1.6	-	-	-	2100	-	17	-	-	150	-	DPAK-3 / TO-252-3
ISL9V3040P3	IGBT, 400V, 17A, 1.58V, 300mJ, TO-220 EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free	Active	400	17	1.6	-	-	-	2100	-	17	-	-	150	-	TO-220-3
ISL9V3040S3ST-F085C	IGBT, N-Channel Ignition, D2PAK, 400V, 17A, 1.58V, 300mJ EcoSPARK® I	AEC Qualified PPAP Capable Pb-free	Active	400	17	1.6				1900					150		D2PAK-3 / TO-263-2
ISL9V3040S_F085	IGBT, 400V, 17A, 1.58V, 300mJ, D2PAK EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free	Active	400	17	1.6	-	-	-	2100	-	17	-	-	150	-	D2PAK-3 / TO-263-2
ISL9V5036P_F085	IGBT, 360V, 31A, 1.17V, 500mJ, TO-220 EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free	Active	360			-	-	-	2100	-	32	-	-	250	-	TO-220-3
ISL9V5036S3ST	IGBT, 360V, 31A, 1.17V, 500mJ, D2PAK EcoSPARK® II, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free	Active	360	31	1.6	-	-	-	2100	-	32	-	-	250	-	D2PAK-3 / TO-263-2
ISL9V5045S3ST	IGBT, 450V, 19A, 1.6V, 300mJ, DPAK EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free	Active	450	43	1.6	-	-	-	2100	-	32	-	-	300	-	D2PAK-3 / TO-263-2
ISL9V5045S_F085	IGBT, 450V, 43A, 1.25V, 500mJ, D2PAK EcoSPARK® I, N-ChannelIgnition	AEC Qualified PPAP Capable Pb-free Halide free	Active	450			-	-	-	2100	-	32	-	-	300	-	D2PAK-3 / TO-263-2
NGTB03N60R2DT4G	IGBT, 600 V, 4.5 A, N-Channel	Pb-free Halide free	Active	600	4.5	1.7	1.5	0.027	0.05	65	-	17	5	-	49	Yes	DPAK-3
NGTB05N60R2DT4G	IGBT, 600V, 8A, N-Channel	Pb-free Halide free	Active	600	8	1.65	1.5	0.06	0.188	70	-	30	5	-	56	Yes	DPAK-3
NGTB10N60FG	IGBT N-Channel, 600V, 10A, VCE(sat)=1.5V, TO-220F-3FS	Pb-free Halide free	Active	600	10	1.5	1.3	-	-	70	-	55	5	-	40	Yes	TO-220-3 FullPak
NGTB10N60R2DT4G	IGBT, 600V, 10A, N-Channel	Pb-free Halide free	Active	600	10	1.7	1.5	0.14	0.412	90	-	53	5	-	72	Yes	DPAK-3
NGTB15N120FL2	IGBT 1200V 15A SOLAR/UPS	Pb-free Halide free	Active	1200	15	2	2	0.37	1.2	110	11	109	10	-	294	Yes	TO-247-3
NGTB15N120IHR	IGBT 1200V 15A FS2-RC Induction Heating	Pb-free Halide free	Active	1200	15	2.1	1.75	0.34	-	-	-	160	-	-	333	Yes	TO-247-3
NGTB15N135IHR	IGBT 1350V 15A FS2-RC Induction Heating	Pb-free Halide free	Active	1350	15	2.15	1.85	0.42	-	-	-	156	-	-	357	Yes	TO-247-3
NGTB15N60R2FG	IGBT, 600V, 14A, N-Channel	Pb-free Halide free	Active	600	14	1.85	1.7	0.22	0.55	95	-	80	10	-	54	Yes	TO-220-3 FullPak
NGTB15N60S1	IGBT, /w Diode 600V 15A NPT	Pb-free	Active	600	15	1.5	1.65	0.35	0.55	270	5	88	5	-	117	Yes	TO-220-3
NGTB20N120IHR	IGBT, 1200V 20A FS2-RC Induction Heating	Pb-free Halide free	Active	1200	20	2.1	1.75	0.45	-	-	-	225	-	-	384	Yes	TO-247-3
NGTB20N135IHR	IGBT, 1350V 20A FS2-RC Induction Heating	Pb-free Halide free	Active	1350	20	2.2	1.8	0.6	-	-	-	234	-	-	394	Yes	TO-247-3
NGTB20N60L2TF1G	IGBT, N-Channel 600V, 20A, VCE(sat);1.45V TO-3PF-3L with Low VF SwitchingDiode	Pb-free Halide free	Active	600	20	1.45	1.5	-	-	70	-	84	-	-	64	Yes	TO-3PF-3L
NGTB25N120FL2	IGBT, 1200V 25A FS2 SOLAR/UPS	Pb-free Halide free	Active	1200	25	2	2.1	0.6	1.95	154	15	178	10	-	385	Yes	TO-247-3
NGTB25N120FL3	IGBT, Ultra Field Stop - 1200V 25A	Pb-free Halide free	Active	1200	25	1.7	3	0.7	1	90	12	136	-	-	349	Yes	TO-247-3
NGTB30N120FL2	IGBT, 1200V 30A FS2 Solar/UPS	Pb-free Halide free	Active	1200	30	2	1.75	0.7	2.6	240	18	220	10	-	452	Yes	TO-247-3
NGTB30N135IHR	IGBT, 1350V 30A FS2-RC Induction Heating	Pb-free Halide free	Active	1350	30	2.3	2.1	0.85	-	-	-	234	-	-	394	Yes	TO-247-3
NGTB30N135IHR1	IGBT, 1350V 30A with Monolithic Free Wheeling Diode.	Pb-free Halide free	Active	1350	30	2.4	1.7	0.63	-	-	-	220	-	-	394	No	TO-247-3
NGTB30N60L2WG	IGBT, N-Channel with Low VF Switching Diode, 600V, 30A, VCE(sat)=1.4V	Pb-free Halide free	Active	600	30	1.4	1.7	0.31	1.14	70	-	166	5	-	225	Yes	TO-247
NGTB30N65IHL2	IGBT, 650V 30A FS2 Induction Heating	Pb-free Halide free	Active	650	30	1.7	1.1	0.2	-	430	35	135	-	-	219	Yes	TO-247-3
NGTB35N60FL2	IGBT, 600V 35A FS2 Solar/UPS	Pb-free Halide free	Active	600	35	1.7	2.2	0.28	0.84	68	7	125	5	-	300	Yes	TO-247-3
NGTB35N65FL2	IGBT, 650V 35A FS2 Solar/UPS	Pb-free Halide free	Active	650	35	1.7	2.2	0.28	0.84	68	7	125	5	-	300	Yes	TO-247-3
NGTB40N120FL2	IGBT, 1200V 40A FS2 Solar/UPS	Pb-free Halide free	Active	1200	40	2	2	1.1	3.4	240	18	313	10	-	535	Yes	TO-247-3
NGTB40N120FL2WA	IGBT, 1200 VField Stop II, 40 A	Pb-free Halide free	Active	1200	40	2.1	2	1.1	1.7	270	16	313	-	-	536	Yes	TO-247-4
NGTB40N120FL3	IGBT, Ultra Field Stop -1200V 40A	Pb-free Halide free	Active	1200	40	1.7	3	1.1	1.6	86	12	212	-	-	454	Yes	TO-247-3
NGTB40N120IHR	IGBT, 1200V 40A FS2-RC Induction Heating	Pb-free Halide free	Active	1200	40	2.3	2.1	0.95	-	-	-	225	-	-	384	Yes	TO-247-3
NGTB40N120L3	IGBT, Ultra Field stop - 1200V 40A, Low VCEsat	Pb-free Halide free	Active	1200	40	1.55	3	1.5	1.5	86	12	220	-	-	454	Yes	TO-247-3
NGTB40N120S3	IGBT, 1200V, 40A Low VF FSIII	Pb-free Halide free	Active	1200	40	1.7	2	1.1	2.2	256	19	212	-	-	454	Yes	TO-247-3
NGTB40N135IHR	IGBT, 1350V 40A FS2-RC Induction Heating	Pb-free Halide free	Active	1350	40	2.4	2.3	1.3	-	-	-	234	-	-	394	Yes	TO-247-3
NGTB40N60L2	IGBT, 600V 40A FS2 Low VCEsat	Pb-free Halide free	Active	600	40	2	2.4	0.28	1.17	73	6.7	228	5	-	417	Yes	TO-247-3
NGTB40N65FL2	IGBT, 650V 40A FS2 Solar/UPS	Pb-free Halide free	Active	650	40	1.7	2.2	0.44	0.97	72	6.7	170	5	-	366	Yes	TO-247-3
NGTB40N65IHL2	IGBT, 650V 40A FS2 Induction Heating	Pb-free Halide free	Active	650	45	1.8	1.2	0.36	-	465	36	135	-	-	300	Yes	TO-247-3
NGTB50N120FL2	IGBT, 1200V 50A FS2 Solar/UPS	Pb-free Halide free	Active	1200	50	2.2	2	1.4	4.4	256	19	311	10	-	535	Yes	TO-247-3
NGTB50N60L2	IGBT, 600V 50A FS2 Low VCEsat	Pb-free Halide free	Active	600	50	1.5	1.7	0.6	0.8	67	7.4	310	5	-	500	Yes	TO-247-3
NGTB50N65FL2	IGBT, 650V 50A FS2 Solar/UPS	Pb-free Halide free	Active	650	50	1.8	2.1	0.46	1.5	94	8	220	5	-	417	Yes	TO-247-3
NGTB50N65FL2WA	IGBT, 650 V Field Stop II, 50 A	Pb-free Halide free	Active	650	50	1.8	2.1	0.58	0.48	94	6.5	215	-	-	417	Yes	TO-247-4
NGTB60N65FL2	IGBT, 650V 60A Field Stop 2 IGBT	Pb-free Halide free	Active	650	60	1.64	2.13	0.66	1.59	96	6.8	318	5	-	595	Yes	TO-247-3
NGTB75N65FL2	IGBT, 650V 75A FS2 Solar/UPS	Pb-free Halide free	Active	650	75	1.7	2.2	1	1.5	80	8	310	5	-	595	Yes	TO-247-3
NGTD13R120F2	Rectifier 1200V bare die	Pb-free Halide free	Active	1200	-	-	2.1		-	-	-	-	-	-	-	-
NGTD13T120F2	IGBT, 1200V 15A FS2 bare die	Pb-free Halide free	Active	1200	-	2		-	-	-	-	-	10	-	-	-
NGTD13T65F2	IGBT, 650V 30A FS2 bare die	Pb-free Halide free	Active	650	-	1.6	-	-	-	-	-	-	5	-	-	-
NGTD14T65F2	IGBT, 650V 35A FS2 bare die	Pb-free Halide free	Active	650	-	1.7	-	-	-	-	-	-	10	-	-	-
NGTD15R65F2	Rectifier 650V 75A FS2 bare die	Pb-free Halide free	Active	650	-	-	2.2	-	-	-	-	-	-	-	-	-
NGTD17R120F2	Rectifier 1200V 35A FS2 bare die	Pb-free Halide free	Active	1200	-	-	1.8	-	-	-	-	-	-	-	-	-
NGTD17T65F2	IGBT 600V 40A FS2 bare die	Pb-free Halide free	Active	650	-	1.7	-	-	-	-	-	-	5	-	-	-
NGTD20T120F2	IGBT 1200V 20A FS2 bare die	Pb-free Halide free	Active	1200	-	2	-	-	-	-	-	-	10	-	-	-
NGTD21T65F2	IGBT 650V 45A FS2 bare die	Pb-free Halide free	Active	650	-	1.7	-	-	-	-	-	-	5	-	-	-
NGTD23T120F2	IGBT 1200V 25A FS2 bare die	Pb-free Halide free	Active	1200	-	1.9	-	-	-	-	-	-	10	-	-	-
NGTD28T65F2	IGBT 650V 75A FS2 bare die	Pb-free Halide free	Active	650	-	1.75	-	-	-	-	-	-	5	-	-	-
NGTD30T120F2	IGBT 1200V 40A FS2 bare die	Pb-free Halide free	Active	1200	-	2	-	-	-	-	-	-	10	-	-	-
NGTD5R65F2	Rectifier 650V 20A FS2 bare die	Pb-free Halide free	Active	650	-	-	1.1	-	-	-	-	-	-	-	-	-
NGTD8R65F2	Rectifier 650V 30A FS2 bare die	Pb-free Halide free	Active	650	-	-	2.1	-	-	-	-	-	-	-	-	-
NGTD9R120F2	Rectifier 1200V 15A FS2 bare die	Pb-free Halide free	Active	1200	-	-	2		-	-	-	-	-	-	-	-
NGTG12N60TF1G	IGBT, N-Channel, 600V, 12A, VCE(sat)=1.4V, TO-3PF-3L	Pb-free	Active	600	12	1.4	-	-	-	-	-	84	5	-	54	No	TO-3PF-3L
NGTG15N120FL2	IGBT, 1200V 15A Solar/UPS	Pb-free Halide free	Active	1200	15	2	-	0.37	1.2	-	-	109	10	-	294	No	TO-247-3
NGTG15N60S1	IGBT, 600V 15A NPT	Pb-free	Active	600	15	1.5	-	0.35	0.55	-	-	88	5	-	117	No	TO-220-3
NGTG20N60L2TF1G	IGBT, N-Channel 600V, 20A, VCE(sat);1.45V Single TO-3PF-3L	Pb-free Halide free	Active	600	20	1.45	-	-	-	-	-	84	-	-	64	No	TO-3PF-3L
NGTG25N120FL2	IGBT, 1200V 25A SOLAR/UPS	Pb-free Halide free	Active	1200	25	2	-	0.6	1.95	-	-	178	10	-	385	No	TO-247-3
NGTG35N65FL2	IGBT, 650V 35A FS2 Solar/UPS	Pb-free Halide free	Active	650	35	1.7	-	0.28	0.84	68	7	125	5	-	300	No	TO-247-3
NGTG40N120FL2	IGBT, 1200V 40A SOLAR/UPS	Pb-free Halide free	Active	1200	40	2	-	1.1	3.4	-	-	313	10	-	535	No	TO-247-3
PCFG25T120SQF	Ultra Field Stop IGBT 1200V 25A bare die	Pb-free Halide free	Active	1200	100	1.7						136
PCFG40T65SQF	650V 40A FS4 IGBT Wafer Sales	Pb-free Halide free	Active		40A	1.6V
PCFG50T65SQF	650V 50A FS4 IGBT Wafer Sales	Pb-free Halide free	Active		50A	1.6V						99nC
PCFG60T120SQF	Ultra Field Stop IGBT 1200V 60A bare die	Pb-free Halide free	Active	1200	240	1.7
PCFG75T120SQF	Ultra Field Stop IGBT 1200V 75A bare die	Pb-free Halide free	Active	1200	300	1.7						399
PCFG75T65LQF	PCFG75T65LQF	Pb-free Halide free	Active
PCFG75T65MQF	IGBT 650V, 75A	Pb-free Halide free	Active
PCFG75T65SQF	650V 75A FS4 IGBT Wafer Sales	Pb-free Halide free	Active		75A	1.6V						128nC
PCGA160T65NF8	IGBT, 650 V, 160 A Field Stop Trench	AEC Qualified PPAP Capable Pb-free Halide free	Active	650	-	2.15	-	-	-	-	-	167	6	-	-	No
PCGA200T65NF8	IGBT, 650 V, 200 A Field Stop Trench	AEC Qualified PPAP Capable Pb-free Halide free	Active	650	-	1.53	-	-	-	-	-	229	5	-	-	No
PCGA200T65NF8M1	IGBT 650 V, 200 A Field Stop Trench Gen3 (FS3) Bare Die with SolderableTop Metal. Pairing with PCRKA20065F8M1	AEC Qualified PPAP Capable Pb-free Halide free	Active
PCGA300T65DF8	IGBT, 650 V, 300 A Field Stop Trench	AEC Qualified PPAP Capable Pb-free Halide free	Active	650	-	1.15	-	-	-	-	-	312	5	-	-	No
PCGA300T65DF8M1	PCGA300T65DF8M1	AEC Qualified PPAP Capable Pb-free Halide free	Active
PCGLA200T75NF8	IGBT bare die 750V 200A	AEC Qualified PPAP Capable Pb-free Halide free	Active
PCRKA16065F8	Extremefast (EF) diode 650V / 160A	AEC Qualified PPAP Capable Pb-free Halide free	Active	650	-	-	1.4	-	-	132	50	-	-	-	-	No
PCRKA20065F8M1	Extremefast (EF) diode, 650 V, 200 A, Bare Die with Solderable Top Metal.Pairing with PCGA200T65NF8M1	AEC Qualified PPAP Capable Pb-free Halide free	Active
PCRKA20075F8	Diode bare die 750V 200A	AEC Qualified PPAP Capable Pb-free Halide free	Active
PCRKA30065F8M1	Extremefast (EF) diode, 650 V, 300 A Bare Die with Solderable Top Metal.Pairing with PCGA300T65DF8M1	AEC Qualified PPAP Capable Pb-free Halide free	Active
SGF23N60UF	IGBT, 600V, PT	Pb-free	Active	600	12	2.1	-	0.135	0.115	-	-	-	-	-	75	No	TO-3PF-3L
SGF5N150UF	IGBT, Discrete, High Performance	Pb-free	Active	1500	10	4.7	-	0.1	0.19	-	-	30	-	-	62.5	No	TO-3PF-3L
SGH40N60UF	IGBT, 600V, PT	Pb-free	Active	600	20	2.1	-	0.2	0.16	-	-	97	-	-	160	No	TO-3P-3L
SGL50N60RUFD	IGBT, 600V, 50A, Short Circuit Rated	Pb-free	Active	600	50	2.2	1.9	1.03	1.68	140	6	145	-	-	250	Yes	TO-264-3
SGP10N60RUFD	IGBT, 600V, 10A, Short Circuit Rated	Pb-free	Active	600	10	2.2	1.4	0.215	0.141	60	3.5	30	-	-	75	Yes	TO-220-3
SGP23N60UF	IGBT, 600V, PT	Pb-free	Active	600	12	2.1	-	0.135	0.115	-	-	-	-	-	100	No	TO-220-3
SGS10N60RUFD	IGBT, 600V, 10A, Short Circuit Rated	Pb-free	Active	600	10	2.2	1.4	0.215	0.141	60	3.5	30	10	-	55	Yes	TO-220-3 FullPak
TIG056BF	IGBT, N-Channel, 240 A, 430 V	Pb-free	Active	430	240	3.6	-	-	-	-	-	-	-	-	30	No	TO-220-3 FullPak
TIG058E8	IGBT, N-Channel, 400V, 150A, VCE(sat)=4V, Single ECH8	Pb-free Halide free	Active	400	150	4	-	-	-	-	-	-	-	-	-	No	SOT-28 FL / ECH-8
TIG065E8	IGBT, N-Channel, 400V, 150A, VCE(sat);4.2V, Single ECH8	Pb-free Halide free	Active	400	150	4.2	-	-	-	-	-	-	-	-	-	No	SOT-28 FL / ECH-8
TIG067SS	IGBT, 400V, 150A, VCE(sat);3.8V, Single N-Channel	Pb-free Halide free	Active	400	150	3.8	-	-	-	-	-	-	-	-	1.2	No	SOIC-8
TIG074E8	IGBT, N-Channel 400V, 150A, VCE(sat); 3.8V Single ECH8	Pb-free Halide free	Active	400	150	3.8	-	-	-	-	-	-	-	-	-	No	SOT-28 FL / ECH-8

微处理器

电源与外围

汽车电子

物联网（IoT）解决方案

汽车电子解决方案

onsemi IGBT

onsemi IGBT特点
