Nexperia 双低VCEsat (BISS)晶体管-广州立功科技股份有限公司

选型表下载

Type number	Package version	Package name	Size (mm)	Product status	Polarity	number of transistors	Ptot [max] (mW)	VCEO [max] (V)	IC [max] (A)	VCEsat [max] (NPN) (mV)	VCEsat [max] (PNP) (mV)	RCEsat@IC [max]; IC/IB =10 [typ] (mΩ)	hFE [min]	fT [typ] (MHz)
PBSS4112PAN	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	NPN	2	1040	120	1	220		240	240	120
PBSS4112PANP	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	NPN/PNP	2	1040	120	1	220	-480	440	240	120
PBSS4130PAN	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	NPN	2	1040	30	1	190		190	240	165
PBSS4130PANP	SOT1118	DFN2020-6	2 x 2 x 0.65	Production
PBSS4160PAN	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	NPN	2	1040	60	1	220		240	290	175
PBSS4160PANP	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	NPN/PNP	2	1040	60	1	220	-340	360	290	175
PBSS4160PANPS	SOT1118D	DFN2020D-6	2 x 2 x 0.65	Production	NPN/PNP	2	1040	60	1	220	-340	360	290	175
PBSS4160PANS	SOT1118D	DFN2020D-6	2 x 2 x 0.65	Production	NPN	2	1040	60	1	220		240	290	175
PBSS4220PANS	SOT1118D	DFN2020D-6	2 x 2 x 0.65	Production	NPN	2		20	2	320		170	250	120
PBSS4230PAN	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	NPN	2	1040	30	2	290		145	250	120
PBSS4230PANP	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	NPN/PNP	2	1040	30	2	290	-390	195	260	120
PBSS4260PAN	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	NPN	2	1040	60	2	330		165	290	140
PBSS4260PANP	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	NPN/PNP	2	1040	60	2	330	-500	250	290	140
PBSS4260PANPS	SOT1118D	DFN2020D-6	2 x 2 x 0.65	Production	NPN/PNP	2		60	2	350	-500	310	250	140
PBSS4260PANS	SOT1118D	DFN2020D-6	2 x 2 x 0.65	Production	NPN	2		60	2	350		200	250	140
PBSS5112PAP	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	PNP	2	1040	-120	-1		-480	440	190	100
PBSS5130PAP	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	PNP	2	1040	-30	-1		-250	250	250	125
PBSS5160PAP	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	PNP	2	1040	-60	-1		-340	360	170	125
PBSS5160PAPS	SOT1118D	DFN2020D-6	2 x 2 x 0.65	Production	PNP	2	1040	-60	-1		-340	360	170	125
PBSS5220PAPS	SOT1118D	DFN2020D-6	2 x 2 x 0.65	Production	PNP	2		-20	-2		-390	220	250	95
PBSS5230PAP	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	PNP	2	1040	-30	-2		-390	195	260	95
PBSS5255PAPS	SOT1118D	DFN2020D-6	2 x 2 x 0.65	Production	PNP	1	960	-55	-2		-450	250	170	100
PBSS5260PAP	SOT1118	DFN2020-6	2 x 2 x 0.65	Production	PNP	2	1040	-60	-2		-500	250	170	100
PBSS5260PAPS	SOT1118D	DFN2020D-6	2 x 2 x 0.65	Production	PNP	2		-60	-2		-390	310	170	100
PBSS2515VPN	SOT666	SOT666	1.6 x 1.2 x 0.55	Production	NPN/PNP	2	300	15	0.5	250	-250	500	200	420
PBSS2515VS	SOT666	SOT666	1.6 x 1.2 x 0.55	Production	NPN	2	300	15	0.5	250		500	200	420
PBSS2515YPN	SOT363	TSSOP6	2.1 x 1.25 x 0.95	Production	NPN/PNP	2	300	15	0.5	250	-250	500	200	420
PBSS3515VS	SOT666	SOT666	1.6 x 1.2 x 0.55	Production	PNP	2	300	-15	-0.5		-250	500	200	280
PBSS4021SN	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	NPN	2	1400	20	7.5	275		35	300	115
PBSS4021SP	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	PNP	2	1400	-20	-6.3		-350	54	250	105
PBSS4021SPN	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	NPN/PNP	2	1400	20	7.5	275	-350	54	300	115
PBSS4032SN	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	NPN	2	1400	30	5.7	250		62.5	300	140
PBSS4032SP	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	PNP	2	1400	-30	-4.8		-390	98	200	115
PBSS4032SPN	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	NPN/PNP	2	1400	30	5.7	250	-390	98	300	140
PBSS4041SN	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	NPN	2	1400	60	6.7	350		48	300	130
PBSS4041SP	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	PNP	2	1400	-60	-5.9		-275	70	200	110
PBSS4041SPN	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	NPN/PNP	2	1400	60	6.7	350	-275	70	300	130
PBSS4140DPN	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	Production	NPN/PNP	2	600	40	1	500	-500	500	300
PBSS4160DPN	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	Production	NPN/PNP	2	560	60	0.87	250	-330	330	250	220
PBSS4160DS	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	Production	NPN	2	560	60	0.87	250		250	250	220
PBSS4240DPN	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	Production	NPN/PNP	2	600	40	1.35	400	-530	260	300
PBSS4350SPN	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	NPN/PNP	2	1200	50	2.7	340	-370	140	300
PBSS4350SS	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	NPN	2	1200	50	2.7	340		130	300
PBSS5160DS	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	Production	PNP	2	560	-60	-0.77		-330	330	200	185
PBSS5350SS	SOT96-1	SO8	4.9 x 3.9 x 1.75	Production	PNP	2	1200	-50	-2.7		-370	140	200
