Nexperia 单NPN型低VCEsat (BISS)晶体管-广州立功科技股份有限公司

选型表下载

Type number	Package version	Package name	Size (mm)	transistor polarity	Ptot [max] (mW)	VCEO [max] (V)	IC [max] (A)	ICM [max] (A)	hFE [min]	hFE [typ]	fT [min] (MHz)	fT [typ] (MHz)	RCEsat [typ] (mΩ)	RCEsat [max] (mΩ)	VCEsat [max] (mV)
2PD2150	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2000	20	3	5	180			220			500
PBSS4130QA	SOT1215	DFN1010D-3	1.1 x 1 x 0.37	NPN	1000	30	1	1.5	250	430	130	190	175	235	245
PBSS4160QA	SOT1215	DFN1010D-3	1.1 x 1 x 0.37	NPN	1000	60	1	1.5	230	400	120	180	170	235	245
PBSS4230QA	SOT1215	DFN1010D-3	1.1 x 1 x 0.37	NPN	1000	30	2	3	250	430	130	190	135	180	360
PBSS4260QA	SOT1215	DFN1010D-3	1.1 x 1 x 0.37	NPN	1000	60	2	3	235	400	120	180	130	180	370
PBSS301ND	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	NPN	2500	20	4	15	300	450		100	50	70	420
PBSS301NX	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2100	12	5.3	10.6	300	530		140	28; 32	40; 48	200
PBSS301NZ	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	2000	12	5.8	11.6	300	530		140	30; 35	43; 52	235
PBSS302ND	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	NPN	2500	40	4	15	300	500		150			450
PBSS302NX	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2100	20	5.3	10.6	300	570		140			220
PBSS302NZ	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	2000	20	5.8	11.6	300	570		140			250
PBSS303ND	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	NPN	2500	60	1	6	345	570		140	68	90	515
PBSS303NX	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2100	30	5.1	10.2	300	480		130			250
PBSS303NZ	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	2000	30	5.5	11	300	480		130			265
PBSS304ND	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	NPN	2500	80	1	6	240	360		140	68	88	505
PBSS304NX	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2100	60	4.7	9.4	300	520		130	37; 48	53; 73	290
PBSS304NZ	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	2000	60	5.2	10.4	300	520		130	39; 51	55; 76	305
PBSS305ND	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	NPN	2500	100	1	4	170	275		140	73	95	360
PBSS305NX	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2100	80	4.6	9.2	300	470		110	38; 53	53; 80	320
PBSS305NZ	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	2000	80	5.1	10.2	300	470		110	40; 56	56; 85	340
PBSS306NX	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2100	100	4.5	9	200	330		110	40	56	245
PBSS306NZ	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	2000	100	5.1	10.2	200	330		110	43	60	300
PBSS2515M	SOT883	DFN1006-3	1.0 x 0.6 x 0.48	NPN	430	15	0.5	1	200		250	420	360	500	250
PBSS2515MB	SOT883B	DFN1006B-3	1.0 x 0.6 x 0.37	NPN	590	15	0.5	1	200		250	420	360	500	250
PBSS2540M	SOT883	DFN1006-3	1.0 x 0.6 x 0.48	NPN	430	40	0.5	1	200		250	450			250
PBSS2540MB	SOT883B	DFN1006B-3	1.0 x 0.6 x 0.37	NPN	590	40	0.5	1	200		250	450			250
PBSS4021NT	SOT23	SOT23	2.9 x 1.3 x 1	NPN	1100	20	4.3	8	300	550		165	36	55	265
PBSS4021NX	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2500	20	7	15	300	550		115	19	28	210
PBSS4021NZ	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	2600	20	8	20	300	550		95	14	20	170
PBSS4032ND	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	NPN	1000	30	3.5	6	300	500		135	50	75	300
PBSS4032NT	SOT23	SOT23	2.9 x 1.3 x 1	NPN	1100	30	2.6	5	300	500		180	76	105	320
PBSS4032NX	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2500	30	4.7	10	300	500		145	45	62.5	375
PBSS4032NZ	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	2000	30	4.9	10	300	500		145	45	62.5	375
PBSS4041NT	SOT23	SOT23	2.9 x 1.3 x 1	NPN	1100	60	3.8	8	300	500		175	46	66	300
PBSS4041NX	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2500	60	6.2	15	300	500		130	25	35	320
PBSS4041NZ	SOT223	SC-73	6.5 x 3.5 x 1.65
PBSS4120T	SOT23	SOT23	2.9 x 1.3 x 1	NPN	480	20	1	3	350	470	100			220	250
PBSS4130T	SOT23	SOT23	2.9 x 1.3 x 1	NPN	480	30	1	3	350	470	100			240	270
PBSS4140T	SOT23	SOT23	2.9 x 1.3 x 1	NPN	450	40	1	2	300		150		260	500	500
PBSS4140U	SOT323	SC-70	2 x 1.25 x 0.95	NPN	350	40	1	2	300		150		260	500	500
PBSS4160T	SOT23	SOT23	2.9 x 1.3 x 1	NPN	1250	60	0.9	2	250	400	150	220	200	250	250
PBSS4160U	SOT323	SC-70	2 x 1.25 x 0.95	NPN	415	60	0.75	2	250	500	150	220	230	280	280
PBSS4160V	SOT666	SOT666	1.6 x 1.2 x 0.55	NPN	500	60	0.9	2	250	400	150	220	200	250	250
PBSS4160X	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	1350	60	1	2	170			180			200
PBSS4220V	SOT666	SOT666	1.6 x 1.2 x 0.55	NPN	900	20	2	4	220	480		210	140	175	355
PBSS4230T	SOT23	SOT23	2.9 x 1.3 x 1	NPN	480	30	2	3	350	470	100	230			320
PBSS4240T	SOT23	SOT23	2.9 x 1.3 x 1	NPN	480	40	2	3	350	470	100	230	140	200	320
PBSS4240V	SOT666	SOT666	1.6 x 1.2 x 0.55	NPN	1200	40	2	3	300		150		150	190	400
PBSS4240X	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	1350	40	2	3	300		150				510
PBSS4240Y	SOT363	TSSOP6	2.1 x 1.25 x 0.95	NPN	430	40	2	3	350	470	100	230	140	200	320
PBSS4240Z	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	1350	40	2	3	300		150			275	550
PBSS4250X	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	1000	50	2	5	300		100			160	380
PBSS4320T	SOT23	SOT23	2.9 x 1.3 x 1	NPN	1200	20	2	5	220		100		80	105	310
PBSS4320X	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	1600	20	3	5	220		100				310
PBSS4330PA	SOT1061	DFN2020-3	2 x 2 x 0.65	NPN	2100	30	3	5	300	465	100	210	75	100	300
PBSS4330PAS	SOT1061D	DFN2020D-3	2 x 2 x 0.65	NPN	2500	30	3	5	300	465	100	210	75	100	300
PBSS4330X	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	1600	30	3	5	300		100		80	100	300
PBSS4350D	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	NPN	750	50	3	5	200		100		110	145	290
PBSS4350T	SOT23	SOT23	2.9 x 1.3 x 1	NPN	1200	50	2	5	300		100				370
PBSS4350X	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	1600	50	3	5	300		100				370
PBSS4350Z	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	2000	50	3	5	200		100				290
PBSS4360PAS	SOT1061D	DFN2020D-3	2 x 2 x 0.65	NPN	2500	60	3	6	200	380	75	160			325
PBSS4360X	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	1350	60	3	6	200		75	145			400
PBSS4360Z	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	2000	60	3	6	200		75	145		140	400
PBSS4420D	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	NPN	2500	20	4	15	300	450		100			420
PBSS4440D	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	NPN	2500	40	4	15	300			150			450
PBSS4480X	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2500	80	4	10	250	400	120	150			270
PBSS4520X	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2500	20	5	10	300	450	100	125			220
PBSS4540X	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2500	40	4	10	300		70		40	71	355
PBSS4540Z	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	2000	40	5	10	300	500	70	130			355
PBSS4560PA	SOT1061	DFN2020-3	2 x 2 x 0.65	NPN	2100	60	6	7	280	440	90	150	34	48	290
PBSS4580PA	SOT1061	DFN2020-3	2 x 2 x 0.65	NPN	2100	80	5.6	7	270	425	95	155	40	57	360
PBSS4612PA	SOT1061	DFN2020-3	2 x 2 x 0.65	NPN	2100	12	6	7	280	440	50	80	33	46	275
PBSS4620PA	SOT1061	DFN2020-3	2 x 2 x 0.65	NPN	2100	20	6	7	280	440	50	80			275
PBSS4630PA	SOT1061	DFN2020-3	2 x 2 x 0.65
PBSS8110D	SOT457	SC-74; TSOP6	2.9 x 1.5 x 1	NPN	700	100	1	3	150		100		160	200	200
PBSS8110T	SOT23	SOT23	2.9 x 1.3 x 1	NPN	480	100	1	3	150		100		165	200	200
PBSS8110X	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	2000	100	1	3	150		100		165	200	200
PBSS8110Y	SOT363	TSSOP6	2.1 x 1.25 x 0.95	NPN	625	100	1	3	150		100		160	200	200
PBSS8110Z	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	1400	100	1	3	150		100		160	200	200
PBSS8510PA	SOT1061	DFN2020-3	2 x 2 x 0.65	NPN	2100	100	5.2	6	180	285	95	150	48	65	340
PMMT491A	SOT23	SOT23	2.9 x 1.3 x 1	NPN	250	40	1	2	300		150		230		500
