| Part No. | 主频(MHz) | Flash | SRAM | WDG (16bit) | GPTM (16bit) | Adv TM (16bit) | Bsc TM (16bit) | SysTick (24bit) | WDG | RTC | USART+UART | I2C | SPI | CAN2.0B 2.0 FS | USB | I2S | SDIO | LCD-TFT | Cam era | MAC | /Hash | RAM | 12bit ADC Units (CHs) | 12bit DAC Units | Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| GD32F205RCT6 | 120 | 256K | 128K | up to 51 | 10 | 2 | 2 | 1 | 2 | 1 | 4+2 | 3 | 3 | 2 | OTG | 2 | 1 | 3(16) | 2 | LQFP64 | |||||
| GD32F205RET6 | 120 | 512K | 128K | up to 51 | 10 | 2 | 2 | 1 | 2 | 1 | 4+2 | 3 | 3 | 2 | OTG | 2 | 1 | 3(16) | 2 | LQFP64 | |||||
| GD32F205RGT6 | 120 | 1024K | 256K | up to 51 | 10 | 2 | 2 | 1 | 2 | 1 | 4+2 | 3 | 3 | 2 | OTG | 2 | 1 | 3(16) | 2 | LQFP64 | |||||
| GD32F205RKT6 | 120 | 3072K | 256K | up to 51 | 10 | 2 | 2 | 1 | 2 | 1 | 4+2 | 3 | 3 | 2 | OTG | 2 | 1 | 3(16) | 2 | LQFP64 | |||||
| GD32F205VCT6 | 120 | 256K | 128K | up to 82 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 | |||
| GD32F205VET6 | 120 | 512K | 128K | up to 82 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 | |||
| GD32F205VGT6 | 120 | 1024K | 256K | up to 82 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 | |||
| GD32F205VKT6 | 120 | 3072K | 256K | up to 82 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 | |||
| GD32F205ZCT6 | 120 | 256K | 128K | up to 114 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 | |||
| GD32F205ZET6 | 120 | 512K | 128K | up to 114 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 | |||
| GD32F205ZGT6 | 120 | 1024K | 256K | up to 114 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 | |||
| GD32F205ZKT6 | 120 | 3072K | 256K | up to 114 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 | |||
| GD32F207RCT6 | 120 | 256K | 128K | up to 51 | 10 | 2 | 2 | 1 | 2 | 1 | 4+2 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 3(16) | 2 | LQFP64 | ||
| GD32F207RET6 | 120 | 512K | 128K | up to 51 | 10 | 2 | 2 | 1 | 2 | 1 | 4+2 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 3(16) | 2 | LQFP64 | ||
| GD32F207RGT6 | 120 | 1024K | 256K | up to 51 | 10 | 2 | 2 | 1 | 2 | 1 | 4+2 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 3(16) | 2 | LQFP64 | ||
| GD32F207RKT6 | 120 | 3072K | 256K | up to 51 | 10 | 2 | 2 | 1 | 2 | 1 | 4+2 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 3(16) | 2 | LQFP64 | ||
| GD32F207VCT6 | 120 | 256K | 128K | up to 82 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 |
| GD32F207VET6 | 120 | 512K | 128K | up to 82 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 |
| GD32F207VGT6 | 120 | 1024K | 256K | up to 82 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 |
| GD32F207VKT6 | 120 | 3072K | 256K | up to 82 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 1 | 1/0 | 3(16) | 2 | LQFP100 |
| GD32F207ZCT6 | 120 | 256K | 128K | up to 114 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 |
| GD32F207ZET6 | 120 | 512K | 128K | up to 114 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 |
| GD32F207ZGT6 | 120 | 1024K | 256K | up to 114 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 |
| GD32F207ZKT6 | 120 | 3072K | 256K | up to 114 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP144 |
| GD32F207IET6 | 120 | 512K | 128K | up to 140 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP176 |
| GD32F207IGT6 | 120 | 1024K | 256K | up to 140 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP176 |
| GD32F207IKT6 | 120 | 3072K | 256K | up to 140 | 10 | 2 | 2 | 1 | 2 | 1 | 4+4 | 3 | 3 | 2 | OTG | 2 | 1 | 1 | 1 | 1 | 1 | 1/1 | 3(24) | 2 | LQFP176 |
基于Arm® Cortex®-M3内核的高性价比增强型GD32F205和GD32F207系列微控制器。GD32F2系列在现有GD32F1产品的基础上提供了全面增强的处理能力与全新的外设接口资源。除了具有Cortex®-M3 MCU业界最大的闪存容量外，还加强了对视频图像、液晶显示、存储扩展以及高速信号采集等应用的支持，并配备了增强的硬件加密模块与安全架构。
- GD32F205系列MCU最高时钟频率为120MHz
- 为应对多个外设同时运行和嵌入式软件协议栈的资源开销，配备了256KB到3072KB的较大容量内置Flash及128KB到256KB的SRAM
- 内核访问闪存高速零等待，最高主频下的工作性能可达150DMIPS，同主频下的代码执行效率比市场同类Cortex®-M3产品提高30-40%
- 增强型GD32F207系列MCU最高时钟频率为120MHz
- 为应对多个外设同时运行和嵌入式软件协议栈的资源开销，配备了256KB到3072KB的超大容量内置Flash及128KB到256KB的SRAM
- 内核访问闪存高速免等待，最高主频下的工作性能可达150DMIPS
