Type number	Package version	Package name	Size (mm)	transistor polarity	VCEO [max] (V)	IC [max] (mA)	hFE [max]	hFE [min]	fT [min] (MHz)	toff (ns)	Complement	Complement	Ptot [max] (mW)
BSR14	SOT23	SOT23	2.9 x 1.3 x 1	NPN	40	800	300	100		250		BSR16	250
BSR16	SOT23	SOT23	2.9 x 1.3 x 1	PNP	-60	-600	300	100	200	365		BSR14	250
BSV52	SOT23	SOT23	2.9 x 1.3 x 1	NPN	12	100	120	40		20			250
MMBT2222A	SOT23	SOT23	2.9 x 1.3 x 1	NPN	40	600	300	100		250			250
MMBT3904	SOT23	SOT23	2.9 x 1.3 x 1	NPN	40	200	300	100	300		MMBT3906	MMBT3906	250
MMBT3906	SOT23	SOT23	2.9 x 1.3 x 1	PNP	-40	-200	300	100			MMBT3904	MMBT3904	250
PMBT2222	SOT23	SOT23	2.9 x 1.3 x 1	NPN	30	600	300	100	250	250	PMBT2907	PMBT2907	250
PMBT2222A	SOT23	SOT23	2.9 x 1.3 x 1	NPN	40	600	300	100	300	250	PMBS2907A	PMBT2907A	250
PMBT2222AM	SOT883	DFN1006-3	1.0 x 0.6 x 0.48	NPN	40	600	300	100	300	260		PMBT2907AM	250
PMBT2222AMB	SOT883B	DFN1006B-3	1.0 x 0.6 x 0.37	NPN	40	600	300	100	300	260		PMBT2907AMB	250
PMBT2222AQA	SOT1215	DFN1010D-3	1.1 x 1 x 0.37	NPN	40	600	300	100	300	260		PMBT2907AQA	325
PMBT2222AYS	SOT363	TSSOP6	2.1 x 1.25 x 0.95	NPN	40	600	300	100	300	250		PMBT2907AYS	250
PMBT2369	SOT23	SOT23	2.9 x 1.3 x 1	NPN	15	200	120	40		20			250
PMBT2907	SOT23	SOT23	2.9 x 1.3 x 1	PNP	-40	-600	300	100	200	365	PMBT2222	PMBT2222	250
PMBT2907A	SOT23	SOT23	2.9 x 1.3 x 1	PNP	-60	-600	300	100	200	365	PMBT2222A	PMBT2222A	250
PMBT2907AM	SOT883	DFN1006-3	1.0 x 0.6 x 0.48	PNP	-60	-600	300	100	200	365		PMBT2222AM	250
PMBT2907AMB	SOT883B	DFN1006B-3	1.0 x 0.6 x 0.37	PNP	-60	-600	300	100	200	365		PMBT2222AMB	250
PMBT2907AQA	SOT1215	DFN1010D-3	1.1 x 1 x 0.37	PNP	-60	-600	300	100	200	365		PMBT2222AQA	325
PMBT2907AYS	SOT363	TSSOP6	2.1 x 1.25 x 0.95	PNP	-60	-600	300	100	200	365		PMBT2222AYS	250
PMBT3904	SOT23	SOT23	2.9 x 1.3 x 1	NPN	40	200	300	100	300		PMBT3906	PMBT3906	250
PMBT3904M	SOT883	DFN1006-3	1.0 x 0.6 x 0.48	NPN	40	200	300	100	300	250	PMBT3906M	PMBT3906M	260
PMBT3904MB	SOT883B	DFN1006B-3	1.0 x 0.6 x 0.37	NPN	40	200	300	100	300	250	PMBT3906MB	PMBT3906MB	250
PMBT3904QA	SOT1215	DFN1010D-3	1.1 x 1 x 0.37	NPN	40	200	300	100	300	250			280
PMBT3904RA	SOT1268-1	DFN1412-6	1.4 x 1.2 x 0.47	NPN	40	200	300	100	300	250			325
PMBT3904VS	SOT666	SOT666	1.6 x 1.2 x 0.55	NPN	40	200	300	100	300	250		PMBT3946VPN	240
PMBT3906	SOT23	SOT23	2.9 x 1.3 x 1	PNP	-40	-200	300	100	250	300	PMBT3904	PMBT3904M	250
PMBT3906M	SOT883	DFN1006-3	1.0 x 0.6 x 0.48	PNP	-40	-200	300	100	250	300	PMBT3904M	PMBT3904M	260
PMBT3906MB	SOT883B	DFN1006B-3	1.0 x 0.6 x 0.37	PNP	-40	-200	300	100	250	300	PMBT3904MB	PMBT3904MB	250
PMBT3906VS	SOT666	SOT666	1.6 x 1.2 x 0.55	PNP	-40	-200	300	100	250	300			240
PMBT3946VPN	SOT666	SOT666	1.6 x 1.2 x 0.55	NPN/PNP	40	200	300	100	300	250		PMBT3904VS	240
PMBT4401	SOT23	SOT23	2.9 x 1.3 x 1	NPN	40	600	300	100	250	250	PMBT4403	PMBT4401	250
PMBT4401YS	SOT363	TSSOP6	2.1 x 1.25 x 0.95	NPN	40	600	300	100	250	250		PMBT4403YS	250
PMBT4403	SOT23	SOT23	2.9 x 1.3 x 1	PNP	-40	-600	300	100	200	350	PMBT4401	PMBT4401	250
PMBT4403YS	SOT363	TSSOP6	2.1 x 1.25 x 0.95	PNP	-40	-600	300	100	200	350		PMBT4401YS	250
PMSS3904	SOT323	SC-70	2 x 1.25 x 0.95	NPN	40	100	300	100		1200	PMSS3906		200
PMSS3906	SOT323	SC-70	2 x 1.25 x 0.95	PNP	-40	-100	300	100		700	PMSS3904		200
PMST2222	SOT323	SC-70	2 x 1.25 x 0.95	NPN	30	600	300	100		250			200
PMST2222A	SOT323	SC-70	2 x 1.25 x 0.95	NPN	40	600	300	100		250	PMST2907A		200
PMST2369	SOT323	SC-70	2 x 1.25 x 0.95	NPN	15	200	120	40		20			200
PMST2907A	SOT323	SC-70	2 x 1.25 x 0.95	PNP	-60	-600	300	100	200	300		PMST2222A	200
PMST3904	SOT323	SC-70	2 x 1.25 x 0.95	NPN	40	200	300	100		240	PMST3906		200
PMST3906	SOT323	SC-70	2 x 1.25 x 0.95	PNP	-40	-200	300	100		300	PMST3904		200
PMST4401	SOT323	SC-70	2 x 1.25 x 0.95	NPN	40	600	300	100		250	PMST4403		200
PXT2222A	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	40	600	300	100	300	250	PXT2907A	PXT2907A	1100
PXT2907A	SOT89	SOT89	4.5 x 2.5 x 1.5	PNP	-60	-600	300	100	200	365	PXT2222A	PXT2222A	1100
PXT4401	SOT89	SOT89	4.5 x 2.5 x 1.5	NPN	40	600	300	100		250	PXT4403		1100
PXT4403	SOT89	SOT89	4.5 x 2.5 x 1.5	PNP	-40	-600	300	100		350	PXT4401		1100
PZT2222A	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	40	600	300	100		250	PZT2907A		1150
PZT2907A	SOT223	SC-73	6.5 x 3.5 x 1.65	PNP	-60	-600	300	100		365	PZT2222A		1150
PZT4401	SOT223	SC-73	6.5 x 3.5 x 1.65	NPN	40	600	300	100		250	PZT4403		1150
PZT4403	SOT223	SC-73	6.5 x 3.5 x 1.65	PNP	-40	-600	300	100		350	PZT4401		1150
