Nexperia 低VCEsat (BISS)高压晶体管-广州立功科技股份有限公司

选型表下载

Type number	Package version	Package name	Size (mm)	Product status	Polarity	Ptot [max] (mW)	VCEO [max] (V)	IC [max] (A)	VCEsat [max] (mV)	RCEsat@IC [max];IC/IB =10 [typ] (mΩ)	hFE [min]	fT [typ] (MHz)
PBHV2160Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	NPN	650	600	0.1	125		70
PBHV3160Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	PNP	650	-600	-0.1	-250		70	38
PBHV8115T	SOT23	SOT23	2.9 x 1.3 x 1	Production	NPN	300	150	1	350		100	30
PBHV8115TLH	SOT23	SOT23	2.9 x 1.3 x 1	Production	NPN	300	150	1	350		70	30
PBHV8115X	SOT89	SOT89	4.5 x 2.5 x 1.5	Production	NPN	520	150	1	50		100	30
PBHV8115Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	NPN	700	150	1	350		100	30
PBHV8118T	SOT23	SOT23	2.9 x 1.3 x 1	Production	NPN	300	180	1	50		100	30
PBHV8140Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	NPN	730	400	1	250	150; 150	100	25
PBHV8215Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	NPN	730	150	2	280		100	33
PBHV8515QA	SOT1215	DFN1010D-3	1.1 x 1 x 0.37	Production	NPN	325; 540	150	0.5	200		100	75
PBHV8540T	SOT23	SOT23	2.9 x 1.3 x 1	Production	NPN	300	400	0.5	250		100	30
PBHV8540X	SOT89	SOT89	4.5 x 2.5 x 1.5	Production	NPN	520	400	0.5	250		100	30
PBHV8540Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	NPN	700	400	0.5	250		100	30
PBHV8560Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	NPN	650	600	0.5	100		70
PBHV9040T	SOT23	SOT23	2.9 x 1.3 x 1	Production	PNP	300	-400	-0.25	-200		100	55
PBHV9040X	SOT89	SOT89	4.5 x 2.5 x 1.5	Production	PNP	520	-400	-0.25	-200		100	55
PBHV9040Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	PNP	700	-400	-0.25	-200		100	55
PBHV9050T	SOT23	SOT23	2.9 x 1.3 x 1	Production	PNP	300	-500	-0.15	-200		100	50
PBHV9050Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	PNP	700	-500	-0.25	-350		100	50
PBHV9115T	SOT23	SOT23	2.9 x 1.3 x 1	Production	PNP	300	-150	-1	-300		100	115
PBHV9115TLH	SOT23	SOT23	2.9 x 1.3 x 1	Production	PNP	300	-150	-1	-300		70	55
PBHV9115X	SOT89	SOT89	4.5 x 2.5 x 1.5	Production	PNP	520	-150	-1	-300		100	115
PBHV9115Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	PNP	700	-150	-1	-300		100	115
PBHV9215Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	PNP	730	-150	-2	-350	100; 100	100	35
PBHV9414Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	PNP	650	-140	-4	-550	100; 100	100
PBHV9515QA	SOT1215	DFN1010D-3	1.1 x 1 x 0.37	Production	PNP	325; 540	-150	-0.5	-300		100	75
PBHV9540X	SOT89	SOT89	4.5 x 2.5 x 1.5	Production	PNP	520	-400	-0.5	-400		140	65
PBHV9540Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	PNP	730	-400	-0.5	-320	360; 360	100	30
PBHV9560Z	SOT223	SC-73	6.5 x 3.5 x 1.65	Production	PNP	650	-600	-0.5	-250		70	38
PMBTA44	SOT23	SOT23	2.9 x 1.3 x 1	Production	NPN	250	400	0.3	750		50
PMBTA45	SOT23	SOT23	2.9 x 1.3 x 1	Production	NPN	300	500	0.15	90		50	35
